Pro-Line

Intuitive 2,8” capacitive electronic control, placed in the door for more ergonomic use.
Chilling and freezing cycles which can be controlled by time or by temperature according to the reading of the temperature probe inside the product.
2 additional chilling mode Soft/Hard can be set just after blast chilling freezing process starts.
Soft mode, standard for Chilling cycles, chamber set point during the process keeps -5ºC during the process.
Hard mode, standard for Freezing cycles, chamber set point during the process keeps in -35ºC during the process.
Cycle duration
Chilling cycle: +65° to +3 °C in 90 minutes.
Freezing cycle: +65° to -18 °C in 240 minutes.
Once chilling / freezing cycle is over, devices enter in standby mode, working as refrigerator keeping the temperature between +2° and +5° after chilling and below -18° after freezing cycle.
3 additional cycles for pre-cooling, fish sanitization and ice-cream hardening.
7 preset ready to use chilling cycles and storage capacity of additional 20 personalized recipes.
Internal and external construction entirely made from high quality stainless steel.
60 mm thickness, CFC-free, high quality (40 kg/m3) polyurethane insulation, injected under high pressure. (Except in PBC-03 version which has 35 mm).
Interior with curved joints to facilitate cleaning.
Includes a needle probe to monitor the temperature in the heart of the food product. Heated needle probed available as an optional.
Storing capacity (Except 3 trays version with GN 1/1 only) for GN 1/1 and EN 60x40 trays with 65 mm distance among them.
Easily removable “Ventilation gill” on the front panel to keep cooling unit system ventilated and working more efficiently.
Height adjustable stainless-steel legs. Height of legs could be adjusted individually (130 mm-200 mm) to enable convenient cleaning. (Except in PBC-03 version).
Manual defrost cycle.
Hot gas coming from the compressor is used to automatically evaporate defrost water.
Sealed condenser unit with ventilated condenser.
Ergonomic, stainless-steel made, robust, perfectly integrated handle ensures practical opening of the door avoids dust and dirt collection, being extremely easy to clean.
Hinged door with automatic return for a perfect closing that minimize temperature gain. Doors have a 120° dwell position and close automatically at less than 90°.
Refrigerant gas R-290
Supply voltage: 230 V 1+N – 50 Hz.

Model	Reference	Coolant	Production (kg/cycle) Refrigeration	Production (kg/cycle) Freezing	External W x D x H dimensions (mm)	Cooling Power (W)	Connection Power (W)
PBC-03	19104299	R290	15	6	590 x 700 x 520	490	590
PBC-05	19104360	R290	23	13	790 x 720 x 850	650	1100
PBC-08	19104361	R290	40	24	790 x 820 x 1290	1300	2000
PBC-10	19104362	R290	50	30	790 x 820 x 1290	1300	2000

Technical datasheet
